Specifications
| Nominal Diameter | [VNAC44] DN 25 | 1 in or [VNAC46] DN 40 | 1-1/2 in or [VNAC47] DN 50 | 2 in or [VNAC48] DN 65 | 2-1/2 in or [VNAC4A] DN 80 | 3 in or [VNAC4B] DN 100 | 4 in or [VNAC4C] DN 125 | 5 in or [VNAC4D] DN 150 | 6 in or [VNAD4E] DN 200 | 8 in or [VNAD4F] DN 250 | 10 in or [VNAD4G] DN 300 | 12 in or [VNAD4H] DN 350 | 14 in or [VNAD4K] DN 400 | 16 in or [VNAD4L] DN 450 | 18 in or [VNAD4M] DN 500 | 20 in or [VNAD4N] DN 600 | 24 in |
| Nominal Pressure | [A0] 150 lb RF / ASME B 16.5 (1 to 8 in) or [A0] 150 lb RF / ASME B 16.5 (10 to 24 in) - max working pressure 145 psi |
| System Design / Cable Connection | [1] Compact w/Converter Housing / at Converter or [C] Separate w/SS Connection Box / IP68 Connector |
| Converter Model | [70] IFC 070 C-IP68 / Compact Design or [80] IFC 070 F-IP68 / Field Mount |
| Fixed Electrodes | [C] 304 SS or [B] Hastelloy |
| Construction of Electrodes | [1] Fixed or [C] P/T Sensor |
| Protection Class | [2] IP 68 Factory | w/SS Connection Box or [2] IP 68 Factory | Compact |
| Cable Length | [00] Compact - None or [00] 5 m | 15 ft or [01] 10 m | 30 ft or [04] 25 m | 75 ft |
| Calibration | [00] Standard or [A0] Custody transfer or [H0] 3 points with water acc. ISO/IEC 17025 2) (1 to 6 in) or [H0] 3 points with water acc. ISO/IEC 17025 2) (8 to 12 in) or [H0] 3 points with water acc. ISO/IEC 17025 2) (14 to 24 in) or [X0] KIWA (OIML R49) |
| Finish | [00000000] KROHNE standard or [30000000] KROHNE offshore (1 in) or [30000000] KROHNE offshore (1-1/2 in) or [30000000] KROHNE offshore (2 in) or [30000000] KROHNE offshore (2-1/2 in) or [30000000] KROHNE offshore (3 in) or [30000000] KROHNE offshore (4 in) or [30000000] KROHNE offshore (5 in) or [30000000] KROHNE offshore (6 in) or [30000000] KROHNE offshore (8 in) or [30000000] KROHNE offshore (10 in) or [30000000] KROHNE offshore (12 in) or [30000000] KROHNE offshore (14 in) or [30000000] KROHNE offshore (16 in) or [30000000] KROHNE offshore (18 in) or [30000000] KROHNE offshore (20 in) or [30000000] KROHNE offshore (24 in) or [50000000] KROHNE burial coating (1 in) or [50000000] KROHNE burial coating (1-1/2 in) or [50000000] KROHNE burial coating (2 in) or [50000000] KROHNE burial coating (2-1/2 in) or [50000000] KROHNE burial coating (3 in) or [50000000] KROHNE burial coating (4 in) or [50000000] KROHNE burial coating (5 in) or [50000000] KROHNE burial coating (6 in) or [50000000] KROHNE burial coating (8 in) or [50000000] KROHNE burial coating (10 in) or [50000000] KROHNE burial coating (12 in) or [50000000] KROHNE burial coating (14 in) or [50000000] KROHNE burial coating (16 in) or [50000000] KROHNE burial coating (18 in) or [50000000] KROHNE burial coating (20 in) or [50000000] KROHNE burial coating (24 in) |
| Tagplate | [0300] Standard or [2300] 316 SS Tagplate (120 x 46 mm) or [3300] 316 SS Tagplate (67 x 25 mm) |
| Flange Material | [60] 316L Stainless Steel (1 to 5 in) or [30] 316L Stainless Steel (1 to 5 in, incl. P/T) or [70] 304L Stainless Steel (6 to 8 in) or [20] 304L Stainless Steel (6 to 8 in, incl. P/T) or [10] Carbon Steel (10 in) or [10] Carbon Steel (12 in) or [10] Carbon Steel (14 in) or [10] Carbon Steel (16 in) or [10] Carbon Steel (18 in) or [10] Carbon Steel (20 in) or [10] Carbon Steel (24 in) or [20] 304L Stainless Steel (10 in) or [20] 304L Stainless Steel (12 in) or [20] 304L Stainless Steel (14 in) or [20] 304L Stainless Steel (16 in) or [20] 304L Stainless Steel (18 in) or [20] 304L Stainless Steel (20 in) or [20] 304L Stainless Steel (24 in) |
| Housing Material | [1] Steel |
