Gems Suresite BM-2-T1-S2/.5"-B12/.5"-30.500-30.5-PPI-SPST-S--

Manufacturer: Setra Systems LLC (dba Gems Sensors)

Mfg Product Code: W1108085

Weight: 0.01 lb(s)

Indication Range: Up to 96" of Indication
Specific Gravity: 1
Float Material: Mini Float, 316SS, 1 SG
Max. Pressure: 10
Operating Temp.: 200
Mounting Type: Type BM
Housing Float Material: 316SS
Housing Type: 1-1/4" Tubing
Connection Code T: (T1) Welded Pipe Cap
Connection Code Sa: (S2) 1/2" MNPT Nipple
Connection Code Sb: (S2) 1/2" MNPT Nipple
Connection Code b: (B12) Removable Flange w/1/2" MNPT
Flag Type: Plastic Flags
Switch Module: 86567 SPST, 300F max., 24" Lead
Wire Qty:1
Scale: Feet/Inches
Media Type: Engine Jacket Water
Indicating Length: 30.500"
C to C Length: 30.5"
Critical Dimension: C to C Length
