AVENTICS AS1-SSU Series Electric Filling Unit, 24 VDC, G 1/4, Left Air Supply, 2.5 to 10 bar, 3/2 Directional

Manufacturer: Asco LP

Mfg Product Code: R412010484

Weight: 2.0 lb(s)

Electric Filling Unit, 24 VDC, G 1/4, Left Air Supply, 2.5 to 10 bar, 3/2 Directional

Features

• Activation: Electrically
• Nominal flow Qn: 1300 l/min
• Compressed air connection: G 1/4
• Working pressure min.: 2.5 bar
• Working pressure max: 10 bar
• DC operating voltage: 24 V
• Sealing principle: Soft Seal
• Pilot: Internal
• Connection type: Pipe connection
• Parts: 3/2-directional valve, Filling valve
• Can be assembled into blocks: Can be assembled into blocks
• basic valve with electrical connector: Basic valve with pilot valve
• Type: Poppet valve
• Min. ambient temperature: -10 °C
• Max. ambient temperature: 50 °C
• Medium: Compressed air, Neutral gases
• Max. particle size: 25 µm
• Compressed air connection, exhaust: G 1/4
• Air supply: left
• Nominal flow Qn 1 to 2: 1300 l/min
• Nominal flow Qn 2 to 3: 380 l/min
• Power consumption DC: 2 W
• Duty cycle: 100 %
• Protection class with connection: IP65
• Electrical connection type 2: Plug:
