Representative photo. Please check item description for details.
Puls Power Supply, 960W, 100-240VAC 1PH, 24-28VDC, 40-34.3A
Manufacturer: Puls Lp
Mfg Product Code: QS40.241
Weight: 4.2 lb(s)
On Hand: 3
The Puls QS40.241 is a four-phase DIN rail power supply. It delivers 24V DC output at 40A, designed for high-power industrial applications with demanding requirements. This unit offers high efficiency and robust construction for reliable performance in complex systems.
Features
- AC 100-240 V wide-range input
- Width only 110 mm, weight only 1.9 kg
- 94.6 % full load and excellent partial load efficiencies
- 50 % BonusPower, 1440 W for up to 4 s
- 110 A high peak current for 10ms for easy fuse tripping
- Safe HiccupPLUS overload mode
- Active power factor correction (PFC)
- Negligibly low input inrush current
- Full power between -25 °C and +60 °C
- Current sharing feature for parallel use
- Internal data logging for troubleshooting included
- Remote control of output voltage
- DC-OK relay contact
- Shut-down input
- ATEX and IECEx approved
Puls Power Supply, 960W, 100-240VAC 1PH, 24-28VDC, 40-34.3A
Input Voltage:100-240 VAC
Specifications
| Input Voltage | 100-240 VAC |
