PRDC2 Series, PRDC - Proximity (Diffuse) DC Photo Electric Sensor
Manufacturer: Red Lion Controls, Inc.
Mfg Product Code: PRDC2000
Weight: 0.13 lb(s)
The Model PRDC2 is a miniature, DC powered, Proximity (Diffuse) photo-electric sensor with a 18" (450 mm) maximum detecting distance. This sensor requires no special reflectors or reflective tapes and the limited sensing range reduces detection of background reflections. It is ideally suited for detection of transparent or translucent objects, parts ejected from presses, and rotating targets such as pulley spokes. A modulated “infrared” LED light beam provides immunity to ambient light. In operation, the modulated light beam is reflected by the detected object. This reflected light beam is sensed by a photo-transistor, which in turn energizes the output. Actual sensing range is determined by the surface area and the amount of reflectivity of the object.
Features
- Proximity (Diffuse) Photo Electric Sensor
- Infrared Modulated LED Light Beam
- 10 to 30 VDC Power
- NPN Outputs
- Various Mounting Brackets and Reflective Targets
- NEMA 6
PRDC2 Series, PRDC - Proximity (Diffuse) DC Photo Electric Sensor
Brand_Name:Red Lion
Manufacturer Product Family:PRDC2 Series Miniature Photo‐Electric Sensors
Function:Proximity
Connector 1 Type:Cable, 2 m
Detection Range:Up to 8 in
Specifications
| Brand_Name | Red Lion |
| Manufacturer Product Family | PRDC2 Series Miniature Photo‐Electric Sensors |
| Function | Proximity |
| Connector 1 Type | Cable, 2 m |
| Detection Range | Up to 8 in |
