MP Series, MP75TX - 3/4" Threaded Explosion Proof Magnetic Pickup
Manufacturer: Red Lion Controls, Inc.
Mfg Product Code: MP75TX00
Weight: 0.85 lb(s)
A Magnetic Pickup consists of a permanent magnet, a pole-piece, and a sensing coil encapsulated in a cylindrical case. An object (target) of iron, steel, or other magnetic material, passing closely by the pole-piece causes distortion of the magnetic flux field, which in turn generates a signal voltage. The magnitude of the signal voltage depends on the relative size and magnetism of the target, its speed of approach, and how close it passes the pole-piece.
Features
- 3/4" Threaded Explosion Proof Magnetic Pickup
- Self-Generating, No External Power Required
- Epoxy Encapsulated, Impervious to Dirt, Oil, & Moisture
- Wide Operating Temperature
- In-Line Preamplifier (Signal Booster) - Optional
MP Series, MP75TX - 3/4" Threaded Explosion Proof Magnetic Pickup
Brand_Name:Red Lion
Manufacturer Product Family:MP Series Generaly Duty Magnetic Pick-Ups
Process Connection Type:Threaded
Process Connection Size:3/4"
Connector 1 Type:Wires, 36 in
Min Gear Pitch:12 D.P.
Specifications
| Brand_Name | Red Lion |
| Manufacturer Product Family | MP Series Generaly Duty Magnetic Pick-Ups |
| Process Connection Type | Threaded |
| Process Connection Size | 3/4" |
| Connector 1 Type | Wires, 36 in |
| Min Gear Pitch | 12 D.P. |
