353 Series Pulse Solenoid Valve (8353), 2" NPT, 220 VAC, Aluminum, 2 Way-2/2 NC
Manufacturer: Asco LP
Mfg Product Code: JKF8353G050AC240/60,220/50
Weight: 6.4 lb(s)
Pulse Sol Valve, 2" NPT, 220 VAC, 2 Way-2/2 NC
The ASCO Series 353, also known as 8353, pulse valve is a solenoid pilot operated diaphragm valve specially designed to deliver extremely fast pulsing in reverse-jet dust collector systems. With its high flow rates, higher peak pressure and the fastest response times on the market it delivers optimal filter cleaning performance, while using significantly less air. This results in energy savings for the user. The valve stands out for its long life, high peak pressure, extended temperature range, and faster installation with the patented Quick Mount Clamp connection. To find out how much air you could save, visit our savings calculator.
Features
- Body Material: Aluminum
- Function: 2 way - 2/2 Normally Closed
- Pipe/Port Type & Size: NPT 2
- Valve Actuation: Solenoid
- Kit Number: 316029
- Coil Class: FT
- Coil Number: 238612-058
- Voltage & Frequency: 240, 220 Volts AC with 50/60 Hz
- Watt Rating: 10.1 W
- Item Status: Active
- Temperature: -40°F to 140°F, -4°F to 284°F
- Carton Note: 2 X 2 2NC 10.1/F AC:
This product is no longer available.
353 Series Pulse Solenoid Valve (8353), 2" NPT, 220 VAC, Aluminum, 2 Way-2/2 NC
This product is no longer available.
Pulse Sol Valve, 2" NPT, 220 VAC, 2 Way-2/2 NC
Brand_Name:Asco
Orifice Size:2 in
Process Connection Type:NPT
Max Operating Temperature:284 °F
Process Connection Size:2"
Input Voltage:220 VAC
Function:2 Way 2/2 Normally Closed
Frequency:60 Hz
Body Material:Aluminum
Specifications
| Brand_Name | Asco |
| Orifice Size | 2 in |
| Process Connection Type | NPT |
| Max Operating Temperature | 284 °F |
| Process Connection Size | 2" |
| Input Voltage | 220 VAC |
| Function | 2 Way 2/2 Normally Closed |
| Frequency | 60 Hz |
| Body Material | Aluminum |
