353 Series Pulse Solenoid Valve (8353), 1" NPT, 415 VAC, Aluminum, 2 Way-2/2 NC
Manufacturer: Asco LP
Mfg Product Code: JB8353G053AC415/50D
Weight: 6.4 lb(s)
Pulse Sol Valve, 1" NPT, 415 VAC, 2 Way-2/2 NC
The ASCO Series 353, also known as 8353, pulse valve is a solenoid pilot operated diaphragm valve specially designed to deliver extremely fast pulsing in reverse-jet dust collector systems. With its high flow rates, higher peak pressure and the fastest response times on the market it delivers optimal filter cleaning performance, while using significantly less air. This results in energy savings for the user. The valve stands out for its long life, high peak pressure, extended temperature range, and faster installation with the patented Quick Mount Clamp connection. To find out how much air you could save, visit our savings calculator.
Features
- Body Material: Aluminum
- Function: 2 way - 2/2 Normally Closed
- Pipe/Port Type & Size: NPT 1
- Valve Actuation: Solenoid
- Kit Number: 316563
- Coil Class: FT
- Coil Number: 238210-088-D
- Voltage & Frequency: 415 Volts AC with 50 Hz
- Watt Rating: 6.1 W
- Item Status: Active
- Lead Length: 18 inch
- Carton Note: 1 X 1-1/8 2NC 6.1/F AC:
This product is no longer available.
353 Series Pulse Solenoid Valve (8353), 1" NPT, 415 VAC, Aluminum, 2 Way-2/2 NC
This product is no longer available.
Pulse Sol Valve, 1" NPT, 415 VAC, 2 Way-2/2 NC
Valve: Actuation:Solenoid
Brand_Name:Asco
Orifice Size:1-1/8 in
Process Connection Type:NPT
Max Operating Temperature:284 °F
Process Connection Size:1"
Function:2 Way 2/2 Normally Closed
Frequency:50 Hz
Body Material:Aluminum
Lead Length:18 in
Specifications
| Valve Features | |
|---|---|
| Valve: Actuation | Solenoid |
| Uncategorized | |
|---|---|
| Brand_Name | Asco |
| Orifice Size | 1-1/8 in |
| Process Connection Type | NPT |
| Max Operating Temperature | 284 °F |
| Process Connection Size | 1" |
| Function | 2 Way 2/2 Normally Closed |
| Frequency | 50 Hz |
| Body Material | Aluminum |
| Lead Length | 18 in |
