DA70A FlexEdge Series, 3-Sled 1xRS232 2xRS485 Protocol Gateway
Manufacturer: Red Lion Controls, Inc.
Mfg Product Code: DA70A0GNNNNNN020
Weight: 1.0 lb(s)
The modular design of the DA70A allows for up to three communications sleds to be added as requirements change or new communication standards emerge. Rugged, field-installable PID control and I/O modules ensure a solution that adapts to meet almost any industrial application need.
Overview The modular design of the DA70A allows for up to three communications sleds to be added as requirements change or new communication standards emerge. With advanced networking capabilities, support for 300+ industrial drivers, and IIoT Cloud connectors, communicate with most any brand of PLC or other equipment, and securely transmit data to wherever it is required. Rugged, field-installable PID control and I/O modules ensure a solution that adapts to meet almost any industrial application need, while the diagnostic light ring offers at-a-glance insight into system operation. Powered by Crimson® 3.2, it is easy to configure secure communications or robust automation capabilities in minutes.
Specifications Two 10/100Base-T(X) Ethernet ports One (1) isolated RS-232 serial port Two (2) isolated RS-485 serial ports One (1) USB Host port Onboard memory: 1 GB flash Expansion memory: Up to 256 GB, micro SD 12-24 VDC +/- 15% -40 to 75 C Operating Temperature UL Class 1, Div 2 Certification ATEX / IECEx Certification
Additional Features • IP Fallback, IP Transparency, NAT, and routing capabilities • VPN Client/Server capabilities with certificate generation • 300+ industrial drivers to communicate with anything • Point and click connectivity to IIoT cloud platforms • Embedded OPC UA server and client enables seamless communication with upstream system • Support for any combination of communication sleds • Supports up to 10 I/O or PID control modules • Intuitive diagnostic light ring for at-a-glance system status indication • Future-proof modular design accommodates field-installable sleds • 802.11 b/g/n Wi-Fi Client (with Wi-Fi Communications Sled) • Dual SIM 4G LTE Modem with Active GPS (with Cellular Communications Sled) • Dual RS-232 Serial Ports (with RS-232 Communication Sled) • Dual RS-485 Serial Ports (with RS-485 Communication Sled) • Mixed RS-232/RS-485 Serial Ports (with Mixed Serial Communication Sled)
- Firewall with Access Control
- Routing, Tunneling, IPsec
- VPN Client/Server
- Crimson Protocol Conversion with 300 Driver Support
- IIoT Cloud Connectors
- Sled 1: 1x RS-232, 2x RS-485
- Sled 2: None
- Sled 3: None
- 3 Serial Ports
- 10 I/O Modules
- 2 Ethernet Ports
- USB Device: Yes
- USB Host: Yes
DA70A FlexEdge Series, 3-Sled 1xRS232 2xRS485 Protocol Gateway
Brand_Name:Red Lion
Manufacturer Product Family:DA70A FlexEdge Series
Serial Ports:3
Ethernet Ports:2
Router Type:IIoT & Protocol Conversion
Comm Sleds:3
I/O Modules:10
Feature: USB Device:Yes
Feature: USB Host:Yes
Sled 1:None
Sled 2:None
Sled 3:None
Specifications
| Brand_Name | Red Lion |
| Manufacturer Product Family | DA70A FlexEdge Series |
| Serial Ports | 3 |
| Ethernet Ports | 2 |
| Router Type | IIoT & Protocol Conversion |
| Comm Sleds | 3 |
| I/O Modules | 10 |
| Feature: USB Device | Yes |
| Feature: USB Host | Yes |
| Sled 1 | None |
| Sled 2 | None |
| Sled 3 | None |
