Puls Power Supply, 96W, 380-480VAC 2PH, 12-15VDC, 8-6.4A
Manufacturer: Puls Lp
Mfg Product Code: CT5.121
Weight: 1.2 lb(s)
On Hand: 0
The Puls CT5.121 is a compact DIN rail power supply. It provides 12V DC output at 4A, designed for space-sensitive applications. This unit offers high efficiency and reliable performance for industrial use.
Features
- AC 380-480 V Wide-range input
- Input fuses included
- Requires only two legs of a 3-phase system
- Width only 40 mm
- Efficiency up to 85.8 %
- Input-transient blanking circuit included
- Minimal inrush current surge
- Full power between -25 °C and +60 °C
