Wika 213.40 Series Glycerin Filled Industrial Pressure Gauge, 4" Dial, 0 to 200 bar, 1/4 NPT Brass Center Back Mount
Manufacturer: Wika Instrument Lp
Mfg Product Code: 9318275-0010
Weight: 0.79 lb(s)
213.40.2.5" 200 bar 1/4 NPT center back mount
The Wika 213.40 Series Liquid Filled Industrial Pressure Gauge is engineered for challenging environments where pulsation or vibration are present. Ideal for both gaseous and liquid media that won't obstruct pressure, this gauge excels in hydraulics and compressors.
Featuring a solid forged-brass case and socket, it offers unparalleled durability, ensuring reliability under the toughest conditions. With pressure ranges up to 15,000 psi (1,000 bar), the Wika 213.40, also known as the "hydraulic gauge," is a top choice for mobile and stationary machinery hydraulic applications.
Its vibration and shock-resistant design makes it indispensable in scenarios requiring high resilience. For those seeking exceptional quality and performance, Branom stands out as the premier source for this indispensable industrial tool.
Features
- Bourdon Tube Pressure Gauge, Liquid Filled
- Model: 213.40
- Specifications: According to Data Sheet APM 213.40 (APM 02.06)
- Measuring System: Copper Alloy
- Movement: Copper Alloy
- Nominal Size: 2.5"
- Unit of Outer Scale: Bar
- Measuring Range: Gauge Pressure Range
- Scale Range: 0/200 Bar
- Process Connection: 1/4 NPT
- Connector Location: Center Back Mount
- Case: Forged Brass, Gold Painted
- Bezel Ring: Gold Plated ABS Ring
- Window: Acrylic (PMMA)
- Accuracy Class: +/- 2.5% (ASME B40.100 Grade A)
- Case Filling: Glycerin
- Type: 213.40
- Dial Description:
- Pressure Gauge Standard: US-Standard
- Color for 1. Scale (Outside): Black
- Dial Background: White
- Arcs/Segments: White Band from 0-90 Bar, Green Band from 90-160 Bar, Red Band from 160-200 Bar
- Manufacturer Logo: WIKA®
- Stop Pin on Dial: At Zero
Wika 213.40 Series Glycerin Filled Industrial Pressure Gauge, 4" Dial, 0 to 200 bar, 1/4 NPT Brass Center Back Mount
213.40.2.5" 200 bar 1/4 NPT center back mount
Gauge: Brand:Wika
Gauge: Model:213.40
Gauge: Dial Size:2-1/2 in (63 mm & 68 mm)
Gauge: Scale Range:≥ 6 In.H2O (16 mbar) to < 10 psi (600 mbar)
Gauge: Pressure Type:Gauge Pressure
Gauge: Measuring Principle:Bourdon Tube
Gauge: Fill Type:Liquid Filled / Fillable
Gauge: Product Unit of Measure:bar
Gauge: Process Connection Size:1/4 NPT
Gauge: Process Connection Location:Center Back Mount
Gauge: Wetted Material:Copper Alloy (Brass)
Gauge: Accuracy:±3%
Gauge: Case Material:Brass
Specifications
| Gauge: Brand | Wika |
| Gauge: Model | 213.40 |
| Gauge: Dial Size | 2-1/2 in (63 mm & 68 mm) |
| Gauge: Scale Range | ≥ 6 In.H2O (16 mbar) to < 10 psi (600 mbar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Product Unit of Measure | bar |
| Gauge: Process Connection Size | 1/4 NPT |
| Gauge: Process Connection Location | Center Back Mount |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Accuracy | ±3% |
| Gauge: Case Material | Brass |
