Wika 213.40 Series Brass Liquid Filled Industrial Pressure Gauge, 2.5" Dial, 0 to 600 PSI, 1/4" NPT Center Back Mount w/ Bezel and Mounting Bracket

Manufacturer: Wika Instrument Lp

Mfg Product Code: 9318224-0001

Weight: 0.79 lb(s)

Applications

• For measuring locations with high dynamic pressure loads or vibrations
• For gaseous and liquid media that are not highly viscous or crystallising and will not attack copper alloy parts
• Mining industry
• Hydraulics
• Shipbuilding

Special Features

• Vibration- and shock-resistant
• Especially robust design
• NS 63 [2 ½"] and 100 [4"] with DNV GL approval
• Scale ranges from 0 … 0.6 to 0 … 1,000 bar [0 ... 10 to 0 ... 15,000 psi]

Features

• Bourdon tube pressure gauge, liquid filled
• forged brass case, model 213.40.0XX
• Model: 213.40
• Specifications according to data sheet: APM 213.40 (APM 02.06)
• Measuring System: Copper Alloy
• Movement: copper alloy
• Nominal size: 2.5"
• Unit of outer Scale: psi / -inHg
• Measuring range: gauge pressure range
• Scale range: 0/600 psi
• Process Connection: 1/4 NPT
• Connector location: center back mount
• Case: Forged Brass, Gold Painted
• Mounting flange/bracket: narrow panel ring, polished SS, rolled on, with mouning bracket
• Window: acrylic (PMMA)
• Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
• Case filling: Glycerin
• Type: 213.40
• Dial description:
• Pressure Gauge Standard: US-Standard
• color for 1.scale (outside): black
• dial background: White
• Manufacturer logo: *WIKA®*
• stop pin on dial: at zero
