Representative photo. Please check item description for details.
Wika HPNV Series High Pressure Needle Valve, 316L SS, 3/8" Coned & Threaded, 30000 psi Pressure Rating
Manufacturer: Wika Instrument Lp
Mfg Product Code: 81643049
Weight: 1.0 lb(s)
On Hand: 0
HPNV 30000 PSI 2W SV F/F 3/8 C&T 316L
Applications
- Oil and gas, chemical industry, machine building and automation
- For injection systems, test benches, hydraulic power packs, blow-out protection
- Blasting/cutting with water, high-pressure cleaning
Special features
- Low-wear design due to non-rotating spindle tip in the bonnet
- Low torque and smooth operation of valve handle even at high pressure
- Leak-tested tightness in accordance with BS6755 / ISO 5208 leakage rate A
- Large selection of materials and configurations available
- Customer-specific combination of valves and measuring instruments (instrument hook-up) on request
Features
- HPNV 30000 PSI 2W SV F/F 3/8 C&
- T 316L
- High Pressure Needle Valves
- Rated Pressure: 30000 PSI
- Body Pattern: Two way straight valve F/F
- Size and Connection: 3/8" coned and threaded tube
- Body Material: Stainless steel 316/316L - 1.4401/1.4404 - S31600/S31603
- Spindle tip material: Stainless Steel A564 17-4-PH – 1.4542 - S17400
- Packing Material: PTFE glass filled
- Bonnet design: Standard
- Handle: Standard Anodized Aluminium handle (EN AW-6060 T6)
- Fitting definition: With Glands and Collars included
- Certificates: 3.1 standard certificate as per EN 10204, all wetted parts material
Wika HPNV Series High Pressure Needle Valve, 316L SS, 3/8" Coned & Threaded, 30000 psi Pressure Rating
HPNV 30000 PSI 2W SV F/F 3/8 C&T 316L
Measurement Maximum:0
Process Connection Type:Coned & Threaded
Valve Material:316L SS
Pressure Rating:30000 psi
Measurement Minimum:0
Packings:PTFE
Valve Position:Two Way, Straight
Specifications
| Measurement Maximum | 0 |
| Process Connection Type | Coned & Threaded |
| Valve Material | 316L SS |
| Pressure Rating | 30000 psi |
| Measurement Minimum | 0 |
| Packings | PTFE |
| Valve Position | Two Way, Straight |
