Medium Range 3-Pin Pico Thd 6In (VS25EBMQ-79965)
VS25EBMQ-79965 MEDIUM RANGE 3-PIN PICO THD 6IN
Brand_Name:Banner
Min Operating Temperature:-20 °C
Max Operating Temperature:55 °C
Lens Material:MABS
Power Supply:10-30 VDC
Delay at Power-Up:100 ms
Ingress Protection:IP67
Repeatability (µs):100
Sensing Beam:Infrared LED
Sensing Beam Wavelength:940
Housing Style:Rectangular
Max Sensing Distance:1200 mm
Sensing Mode (Detailed):Emitter
Sensing Mode (General):Opposed
Max Relative Humidity:80% @ 50 °C
Housing Material_:Thermoplastic
Feature: Hazardous Area:No
DeviceNet:No
Feature: IO Link:No
Feature: Quick Disconnect:Yes
Feature: Audible:No
Quick Disconnect Type:M8
Feature: Chemical Resistant:No
Opposed Mode Emitter/Receiver:Emitter
Feature: Water Detection:No
Output Response Time:1 ms ON/0.5 ms OFF
Adjustments:N/A
Feature: Timing (Hold/Delay):No
Feature: Encapsulated:No
Feature: Remote Teach:No
Feature: Intrinsically Safe:No
Connection Type:Pigtail QD, Pigtail QD, Pigtail QD
Country of Origin:US
NEMA / UL:NEMA 6
Indicator Type:LED
Specifications
| Brand_Name | Banner |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 55 °C |
| Lens Material | MABS |
| Power Supply | 10-30 VDC |
| Delay at Power-Up | 100 ms |
| Ingress Protection | IP67 |
| Repeatability (µs) | 100 |
| Sensing Beam | Infrared LED |
| Sensing Beam Wavelength | 940 |
| Housing Style | Rectangular |
| Max Sensing Distance | 1200 mm |
| Sensing Mode (Detailed) | Emitter |
| Sensing Mode (General) | Opposed |
| Max Relative Humidity | 80% @ 50 °C |
| Housing Material_ | Thermoplastic |
| Feature: Hazardous Area | No |
| DeviceNet | No |
| Feature: IO Link | No |
| Feature: Quick Disconnect | Yes |
| Feature: Audible | No |
| Quick Disconnect Type | M8 |
| Feature: Chemical Resistant | No |
| Opposed Mode Emitter/Receiver | Emitter |
| Feature: Water Detection | No |
| Output Response Time | 1 ms ON/0.5 ms OFF |
| Adjustments | N/A |
| Feature: Timing (Hold/Delay) | No |
| Feature: Encapsulated | No |
| Feature: Remote Teach | No |
| Feature: Intrinsically Safe | No |
| Connection Type | Pigtail QD, Pigtail QD, Pigtail QD |
| Country of Origin | US |
| NEMA / UL | NEMA 6 |
| Indicator Type | LED |
