Turck FOUNDATION fieldbus and PROFIBUS-PA, IP66 junction box, 6-channel (JBBS-49SC-T635)
Manufacturer: Turck Incorporated
Mfg Product Code: 6884282
Weight: 4.59 lb(s)
On Hand: 0
FOUNDATION fieldbus and PROFIBUS-PA Features
- IP66 junction box
- 6-channel
- Junction box for wall mounting with PVC cable glands M20 x 1.5
- Short-circuit protection per drop line/spur
- Integrated terminating resistor (activatable)
- Cable shielding: Capacitive or direct connection to housing potential selectable via switch
- Isolated support terminal for optional protective conductor incorporated in cable
- Stainless steel housing
- Pressure compensation element protects against condensation
- Connection of the housing potential via M5 x 1 bolt
Turck FOUNDATION fieldbus and PROFIBUS-PA, IP66 junction box, 6-channel (JBBS-49SC-T635)
Measurement Maximum:0
Case Material:304 SS
Measurement Minimum:0
Country of Origin:DE
Specifications
| Measurement Maximum | 0 |
| Case Material | 304 SS |
| Measurement Minimum | 0 |
| Country of Origin | DE |
