621 Series Explosion-Proof Pressure Transmitter, 0 psig to 200 psig, SS Threaded Connection
Manufacturer: Noshok Inc
Mfg Product Code: 621-200-1-1-2-6
Weight: 0.75 lb(s)
0 to 200 psig, 0.25% Accuracy BFSL, 4 to 20 mA Output, 1/4" National Pipe Thread (NPT) Male Explosion Proof Pressure Transmitter with 1/2" National Pipe Thread (NPT) Conduit (6 ft Cable Attached)
- Current and voltage outputs available
- 316 stainless Steel and Elgiloy wetted parts
- Factory Mutual and Canadian Standards Association approved
- CE compliant to suppress RFI, EMI and ESD
- NACE MR0175/ISO 15156 compliant
- NSI/ISA-12.27.01 approved single seal
Applications:
- Chemical processing
- Gas pressure measurement
- Oil field & offshore
- Mining
- Well head measurement
WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
621 Series Explosion-Proof Pressure Transmitter, 0 psig to 200 psig, SS Threaded Connection
0 to 200 psig, 0.25% Accuracy BFSL, 4 to 20 mA Output, 1/4" National Pipe Thread (NPT) Male Explosion Proof Pressure Transmitter with 1/2" National Pipe Thread (NPT) Conduit (6 ft Cable Attached)
Measurement Maximum:200.0
Process Connection Type:NPT-Male
Pressure Range:0 psig to 200 psig
Min Operating Pressure:0 psig
Max Operating Pressure:200 psig
Min Operating Temperature:-40 °F
Max Operating Temperature:212 °F
Process Connection Size:1/4"
Accuracy:±0.25% full scale (BFSL)
Case Material:316 SS
Wetted Material:316 SS
Measurement Minimum:0
Output Communication Protocol:4-20 mA, 2-wire
Input Voltage:10-30VDC
Ingress Protection:IP67
Response Time:≤1 ms
Electrical Connector Type:1/2 in. NPT Male Conduit w/Integral Cable
Cable Length (ft):6.0
Cord/Cable Length:6 ft
Specifications
| Measurement Maximum | 200.0 |
| Process Connection Type | NPT-Male |
| Pressure Range | 0 psig to 200 psig |
| Min Operating Pressure | 0 psig |
| Max Operating Pressure | 200 psig |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 212 °F |
| Process Connection Size | 1/4" |
| Accuracy | ±0.25% full scale (BFSL) |
| Case Material | 316 SS |
| Wetted Material | 316 SS |
| Measurement Minimum | 0 |
| Output Communication Protocol | 4-20 mA, 2-wire |
| Input Voltage | 10-30VDC |
| Ingress Protection | IP67 |
| Response Time | ≤1 ms |
| Electrical Connector Type | 1/2 in. NPT Male Conduit w/Integral Cable |
| Cable Length (ft) | 6.0 |
| Cord/Cable Length | 6 ft |
