| OBSOLETE | 615 Series High Accuracy Heavy-Duty Pressure Transducer, Internal Diaphragm, -1 psig to 1 psig
Manufacturer: Noshok Inc
Mfg Product Code: 615-30000-2-5-6-25
Weight: 0.45 lb(s)
Pressure Transducer, Wetted Materials: Elgiloy, 13-8PH, 0 psig to 30000 psig, 0.125% Accuracy (BFSL), 0 Vdc to 10 Vdc Output, 9/16-18 UNF 2B HP, M12 x 1 (4 Pin)
- Vacuum ranges through 0 psig to 145,000 psig; absolute ranges from 0 psia to 15 psia through 0 psia to 300 psia
- Current and voltage outputs available
- 316 and 17-4PH Stainless Steel wetted parts
- CE compliant to suppress RFI, EMI and ESD
WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
| OBSOLETE | 615 Series High Accuracy Heavy-Duty Pressure Transducer, Internal Diaphragm, -1 psig to 1 psig
Pressure Transducer, Wetted Materials: Elgiloy, 13-8PH, 0 psig to 30000 psig, 0.125% Accuracy (BFSL), 0 Vdc to 10 Vdc Output, 9/16-18 UNF 2B HP, M12 x 1 (4 Pin)
Measurement Maximum:1.0
Pressure Range:-1 psig to 1 psig
Min Operating Pressure:-1 psig
Max Operating Pressure:1 psig
Min Operating Temperature:-20 °F
Product Unit of Measure:psig
Max Operating Temperature:212 °F
Process Connection Size:9/16"-18
Process Connection Location:Bottom
Accuracy:±0.125% BFSL
Case Material:316 SS
Wetted Material:Elgiloy
Measurement Minimum:-1
Output Communication Protocol:0-10 VDC, 3-wire
Input Voltage:10-30 VDC
Ingress Protection:IP65
Response Time:≤1 ms
Electrical Connector Type:M12 x 1 (4-pin)
Alternative Products
Specifications
| Measurement Maximum | 1.0 |
| Pressure Range | -1 psig to 1 psig |
| Min Operating Pressure | -1 psig |
| Max Operating Pressure | 1 psig |
| Min Operating Temperature | -20 °F |
| Product Unit of Measure | psig |
| Max Operating Temperature | 212 °F |
| Process Connection Size | 9/16"-18 |
| Process Connection Location | Bottom |
| Accuracy | ±0.125% BFSL |
| Case Material | 316 SS |
| Wetted Material | Elgiloy |
| Measurement Minimum | -1 |
| Output Communication Protocol | 0-10 VDC, 3-wire |
| Input Voltage | 10-30 VDC |
| Ingress Protection | IP65 |
| Response Time | ≤1 ms |
| Electrical Connector Type | M12 x 1 (4-pin) |
