| OBSOLETE | 615 Series High Accuracy Heavy-Duty Pressure Transducer, Internal Diaphragm, 0 psig to 30 psig, Hirschmann
Manufacturer: Noshok Inc
Mfg Product Code: 615-30-2-1-2-8
Weight: 0.45 lb(s)
Pressure Transmitter, Wetted Materials: 316 SS, 0 psig to 30 psig, 0.125% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, Hirschmann
- Vacuum ranges through 0 psig to 145,000 psig; absolute ranges from 0 psia to 15 psia through 0 psia to 300 psia
- Current and voltage outputs available
- 316 and 17-4PH Stainless Steel wetted parts
- CE compliant to suppress RFI, EMI and ESD
WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
| OBSOLETE | 615 Series High Accuracy Heavy-Duty Pressure Transducer, Internal Diaphragm, 0 psig to 30 psig, Hirschmann
Pressure Transmitter, Wetted Materials: 316 SS, 0 psig to 30 psig, 0.125% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, Hirschmann
Measurement Maximum:30.0
Process Connection Type:NPT-Male
Max Operating Pressure:30 psid
Case Material:316 SS
Measurement Minimum:0
Output Communication Protocol:4-20 mA, 2-wire
Input Voltage:10-30 VDC
Ingress Protection:IP65
Response Time:≤ 1 ms
Electrical Connector Type:DIN EN 175301-803 Form A
Alternative Products
Specifications
| Measurement Maximum | 30.0 |
| Process Connection Type | NPT-Male |
| Max Operating Pressure | 30 psid |
| Case Material | 316 SS |
| Measurement Minimum | 0 |
| Output Communication Protocol | 4-20 mA, 2-wire |
| Input Voltage | 10-30 VDC |
| Ingress Protection | IP65 |
| Response Time | ≤ 1 ms |
| Electrical Connector Type | DIN EN 175301-803 Form A |
