800 Series Precision Test Pressure Gauge, 0 psi to 1,000 psi, 304SS Rear Flange
Manufacturer: Noshok Inc
Mfg Product Code: 60-800-1000-psi-SSRF
Weight: 2.0 lb(s)
6" 304 SS Case, Copper Alloy Internals, 1,000 psi, 1/4" (NPT) Bottom Precision Test Gauge, SS Rear Flange
- Highly accurate dry gauge
- Vacuum and compound ranges through 0 psi to 6,000 psi
- Beryllium Copper, 316 Stainless Steel, and Brass wetted parts
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
Applications:
- Aerospace equipment
- Gauge repair facilities
- Laboratory & test equipment
- Precision measurement
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
800 Series Precision Test Pressure Gauge, 0 psi to 1,000 psi, 304SS Rear Flange
6" 304 SS Case, Copper Alloy Internals, 1,000 psi, 1/4" (NPT) Bottom Precision Test Gauge, SS Rear Flange
Measurement Maximum:1000.0
Process Connection Type:NPT
Dial Size:6"
Pressure Range:0 psi to 1,000 psi
Min Operating Pressure:0 psi
Max Operating Pressure:1000 psi
Min Operating Temperature:-40 °F
Product Unit of Measure:psi single scale
Max Operating Temperature:180 °F
Process Connection Size:1/4"
Process Connection Location:Bottom
Case Material:304 SS
Wetted Material:Copper Alloy
Measurement Minimum:0
Specifications
| Measurement Maximum | 1000.0 |
| Process Connection Type | NPT |
| Dial Size | 6" |
| Pressure Range | 0 psi to 1,000 psi |
| Min Operating Pressure | 0 psi |
| Max Operating Pressure | 1000 psi |
| Min Operating Temperature | -40 °F |
| Product Unit of Measure | psi single scale |
| Max Operating Temperature | 180 °F |
| Process Connection Size | 1/4" |
| Process Connection Location | Bottom |
| Case Material | 304 SS |
| Wetted Material | Copper Alloy |
| Measurement Minimum | 0 |
