Wika 232.53 Series 2.3" Stainless Steel Dry Pressure Gauge, -100 to 150 kPa, LM
Manufacturer: Wika Instrument Lp
Mfg Product Code: 52987780
Weight: 0.35 lb(s)
232.53.063 -100/+150 kPa 1/4 NPT lower mount
The Wika 232.53 Series Stainless Steel Pressure Gauge is the ideal solution for demanding industrial applications. This gauge is perfectly suited for corrosive environments and works seamlessly with gaseous or liquid media that do not obstruct the pressure system. It is widely used in the process industry, including chemical and petrochemical sectors, power stations, mining operations, both onshore and offshore projects, environmental technology, mechanical engineering, and plant construction.
This advanced pressure gauge features the new FlexWindow option available on 2-1/2” gauges, which enhances readability and durability. It boasts excellent load-cycle stability and shock resistance, making it a reliable choice for high-stress applications. The all stainless steel construction guarantees maximum durability and resistance to corrosion, even in the harshest environments. With the capability to handle positive pressure ranges up to 15,000 psi (1,000 bar), this gauge meets the needs of high-pressure applications with ease.
For those seeking the best in pressure gauge technology, Branom is the top choice for purchasing the Series 232.53. Renowned for exceptional customer care, Branom's expert team is dedicated to providing the best advice and support, ensuring you find the perfect gauge for your requirements.
Features
- Type 23X.5X
- Size: 2.5"
- Material: Stainless Steel
- Bezel: Crimped or removable (53 or 54)
- Model: 232.53.063
- Specifications: 23X.53 and 23X.54
- Case: Non-removable crimp ring
- Scale range: -100/150 kPa
- Process Connection: 1/4 NPT
- Connector location: lower mount
- Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
- Material pressure element: Measuring System 316 SS
- Case filling fluid: prepared for filling
- Window: Polycarbonate
- Dial description:
- Pressure Gauge Standard: US-Standard
- Scale color: black
- Dial background: White
- Manufacturer: WIKA®
- Serial number: ...
Wika 232.53 Series 2.3" Stainless Steel Dry Pressure Gauge, -100 to 150 kPa, LM
232.53.063 -100/+150 kPa 1/4 NPT lower mount
Gauge: Brand:Wika
Gauge: Model:232.53
Gauge: Dial Size:2-1/2 in (63 mm & 68 mm)
Gauge: Scale Range:≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar)
Gauge: Pressure Type:Gauge Pressure
Gauge: Measuring Principle:Bourdon Tube
Gauge: Fill Type:Dry
Gauge: Product Unit of Measure:kPa
Gauge: Process Connection Size:1/4 NPT
Gauge: Process Connection Location:Lower Mount
Gauge: Wetted Material:Stainless Steel
Gauge: Accuracy:±2%
Gauge: Case Material:Stainless Steel
Specifications
| Gauge: Brand | Wika |
| Gauge: Model | 232.53 |
| Gauge: Dial Size | 2-1/2 in (63 mm & 68 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Dry |
| Gauge: Product Unit of Measure | kPa |
| Gauge: Process Connection Size | 1/4 NPT |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Accuracy | ±2% |
| Gauge: Case Material | Stainless Steel |
