Wika 233.50.6" -30 inHg/+30 psi 1/2 NPT Lower Back Mount (copy)

Manufacturer: Wika Instrument Lp

Mfg Product Code: 52924905

Weight: 0.5 lb(s)

Measuring System: Stainless Steel
Case filling: with
Nominal size: 4"
Scale range: -30 inHg/30 psi
2nd Scale / Special Scale: 2nd scale bar
Process Connection: 1/2 NPT
Connector location: lower back mount
Mounting Flange/Bracket: Rear Flange, Stainless Steel
Window: laminated safety glass
Pointer: adjustable pointer
Accuracy Class: +/- 1% (ASME B40.100 Grade 1A)
Case surface: bare case / polished ring
Material pressure element: Measuring System 316L
Case filling fluid: Glycerine
Ingress Protection: IP 65
Permissible medium temperature: + 100 °C
Permissible ambient temperature: -20 ... +60 °C
Pressure Gauge Standard: US-Standard
color for 2.scale (inside): red

Applications

• For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
• Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
• Machine building and general plant construction

Special Features

• Excellent load-cycle stability and shock resistance
• With case filling (model 233.50) for applications with high dynamic pressure loads and vibrations
• Completely from stainless steel
• Scale ranges from 0 … 0.6 to 0 … 1,600 bar [0 ... 10 to 0 ... 20,000 psi]

Features

• Bourdon Tube Pressure Gauges, 4.5" Stainles Steel
• Series, standard case with blow-out plug (50) or
• solid front safety case (30)
• Nominal size: 4.5"
• Measuring System: Stainless Steel
• Case: With Pressure Blowout Disk
• Scale range: 0/100 psi
• Process Connection: 1/2 NPT
• Connector location: lower mount
• Accuracy Class: +/- .5% (ASME B40.100 2A)
• Case surface: bare
• Material pressure element: Measuring System 316L
• Case filling fluid: glycerine-water-mixture
• Set / Drag Pointer: externally adjustable red drag pointer on window
• Window: acrylic (PMMA)
• Ingress Protection: IP 65
• Dial description:
• Pressure Gauge Standard: US-Standard
• color for 1.scale (outside): black
• dial background: White
• *WIKA®*
• serial number on dial: Serial number *...*
• stop pin on dial: at 6 o'clock
