Representative photo. Please check item description for details.
Wika 232.50 Series Gauge, 4" Dial, 0-5000PSI, 1/4" Lower, Adj Drag Pointer, Assembled with L990.34 Series Diaphragm Seal(P/N:50480715) KN2 Silicone DC200 Fill
Manufacturer: Wika Instrument Lp
Mfg Product Code: 52921221
Weight: 5.0 lb(s)
On Hand: 0
Features:
- Assembly Bill Of Material:
- Gauge: 232.50 4 5000PSI 1/4 L DP
- Seal: L990.34.N2FXN2F.SS.SS-0.SS.5K (50480715)
- Fill: KN2 Silicone DC200 50Cst
- Assembly Description:
- Gauge Description:
- 232.50.4" 5000 psi 1/4 NPT lower mount
- Measuring System 316L
- Ingress Protection: IP 65
- +/- 1% (ASME B40.1 Grade 1A)
- Window: laminated safety glass
- adjustable pointer
- externally adjustable red drag pointer on window
- admissible ambient temperature: -40 ... +60 °C
- Permissible medium temperature: + 200 °C
- Pressure Gauge Standard: US-Standard
- *WIKA®* Serial number *...*
- Mounted to:
- Standard Welded Diaphragm Seal - WIKA Type L990.34;
- Instrument Connection: [N2F] 1/4" NPT Female (M6 fill port standard);
- Process Connection: [N2F] 1/4" NPT Female;
- Upper Housing Material: [SS] Stainless Steel 316L (1.4435);
- Lower Housing Material: [SS] Stainless Steel 316L (1.4435);
- Flushing Ports: [-0] Without;
- Diaphragm Material: [SS] Stainless Steel 316L (1.4435);
- Nominal Pressure Rating: [5K] 5000 PSI MWP;
- System Fill Fluid: KN2 Silicone DC200 50Cst
Wika 232.50 Series Gauge, 4" Dial, 0-5000PSI, 1/4" Lower, Adj Drag Pointer, Assembled with L990.34 Series Diaphragm Seal(P/N:50480715) KN2 Silicone DC200 Fill
Measurement Maximum:5000.0
Process Connection Type:NPT
Dial Size:4 in (100 mm)
Process Connection Size:1/4"
Process Connection Location:Bottom
Case Material:316 SS
Wetted Material:316L SS
Measurement Minimum:0
Specifications
| Measurement Maximum | 5000.0 |
| Process Connection Type | NPT |
| Dial Size | 4 in (100 mm) |
| Process Connection Size | 1/4" |
| Process Connection Location | Bottom |
| Case Material | 316 SS |
| Wetted Material | 316L SS |
| Measurement Minimum | 0 |
