Wika 111.12 Series 2" Brass Dry Pressure Gauge, 0 to 30 psi, 2nd Scale kPa, 1/8 NPT, CBM, Black Steel Case
Manufacturer: Wika Instrument Lp
Mfg Product Code: 52869337
Weight: 0.22 lb(s)
111.12 2.0" 30 psi 2nd scale kPa 1/8 NPT center back mount
The model 111 pressure gauges are based on the proven Bourdon tube measuring system. The deflection of the Bourdon tube is transmitted to a movement and indicated.
The modular design enables a multitude of combinations of case materials, process connections, nominal sizes and scale ranges. Due to the high variance, the instrument is suitable for use in a wide range of applications within industry.
For mounting in control panels, the pressure gauges can, depending on the process connection, be fitted with a surface mounting flange or with a triangular profile ring and mounting bracket.
The standard version of the model 111 is manufactured, cost-optimised on modern production lines, in volumes of several million instruments per year.
Applications
- For gaseous and liquid media that are not highly viscous or crystallising and will not attack copper alloy parts
- Pneumatics
- Heating and air-conditioning technology
- Medical engineering
Features
- Type 111.12 ABS or painted steel case back mount
- Specifications according to data sheet: 111.12
- Nominal size: 2.0"
- Unit of outer scale: psi / -inHg
- Measuring range: gauge pressure range
- Scale range: 0/30 psi
- 2nd scale / special scale: 2nd scale kPa
- Process connection: 1/8 NPT
- Connector location: center back mount
- Case: Black steel
- Movement: Standard
- Window: Plastic, clear
- Pointer: Plastic, black
- +/- 3/2/3% (ASME B40.100 Grade B)
- Single packing
- Mounting flange/bracket: Profile ring, steel black, crimped, with steel mounting bracket
- Process connection surface area: Brass
- Dial: Plastic, white, with stop-pin
- US-standard
- Color for 1.scale (outside): Black
- Color for 2.scale (inside): Red
- Dial background: White
- Manufacturer logo: WIKA®
- Stop pin on dial: At zero
Wika 111.12 Series 2" Brass Dry Pressure Gauge, 0 to 30 psi, 2nd Scale kPa, 1/8 NPT, CBM, Black Steel Case
111.12 2.0" 30 psi 2nd scale kPa 1/8 NPT center back mount
Gauge: Brand:Wika
Gauge: Model:111.12
Gauge: Dial Size:2 in (50 mm)
Gauge: Scale Range:≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar)
Gauge: Pressure Type:Gauge Pressure
Gauge: Measuring Principle:Bourdon Tube
Gauge: Fill Type:Dry
Gauge: Product Unit of Measure:psi / inHg
Gauge: 2nd Scale:kPa
Gauge: Process Connection Size:1/8 NPT
Gauge: Process Connection Location:Center Back Mount
Gauge: Wetted Material:Copper Alloy (Brass)
Gauge: Accuracy:±3%
Gauge: Ingress Protection:IP 33
Gauge: Case Material:Steel
Specifications
| Gauge: Brand | Wika |
| Gauge: Model | 111.12 |
| Gauge: Dial Size | 2 in (50 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Dry |
| Gauge: Product Unit of Measure | psi / inHg |
| Gauge: 2nd Scale | kPa |
| Gauge: Process Connection Size | 1/8 NPT |
| Gauge: Process Connection Location | Center Back Mount |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Accuracy | ±3% |
| Gauge: Ingress Protection | IP 33 |
| Gauge: Case Material | Steel |
