Wika 111.11 Series 2" Brass Dry Pressure Gauge, -1 to 1.5 bar, 2nd Scale bar/psi, 1/4 NPT, LM, O2 Cleaned
Manufacturer: Wika Instrument Lp
Mfg Product Code: 50553801
Weight: 0.24 lb(s)
111.11 2.0" (approx. -1/+1.5 bar) -1/2BAR/PSI 1/4 NPT lower mount
Applications
- Compressed gas regulators
- Beverage dispensing machines
- Suitable for all media that will not obstruct the pressure system or attack copper alloy parts
Product features
- UL-listed (UL-252a or UL-404)
- SS Z&N coated or gold-painted steel case
- Free of oil and grease
Features
- Type 111.11 Compressed Gas Regulator Gauge
- Specifications according to data sheet: 111.11
- Nominal Size: 2.0"
- Unit of outer Scale: special pressure range
- Measuring range: vacuum- or compound-range
- Scale range: special (approx. -1/1.5 bar)
- 2nd Scale / Special Scale: -1/2BAR/PSI
- Process Connection: 1/4 NPT
- Connector location: lower mount
- Restrictor: Brass, D 0.3
- Case: SS ZrN plated (brass polished look), Twistlock
- Movement: Standard
- Window: twist-lock polycarbonate
- Pointer: Aluminium, Black
- +/- 3/2/3% (ASME B40.100 Grade B)
- bulk-packing
- Special design features: oil and grease free
- Additional ordering information: FOR CONCOA
- Thread protection: with thread protection
- Process connection surface area: brass
- Dial: Aluminum, White, with Stop Pin
- US-Standard
- color for 1.scale (outside): black
- color for 2.scale (inside): black
- dial background: White
- Manufacturer logo: without
- stop pin on dial: at zero
- additional mark for special design: *use no oil* (red)
Wika 111.11 Series 2" Brass Dry Pressure Gauge, -1 to 1.5 bar, 2nd Scale bar/psi, 1/4 NPT, LM, O2 Cleaned
111.11 2.0" (approx. -1/+1.5 bar) -1/2BAR/PSI 1/4 NPT lower mount
Gauge: Brand:Wika
Gauge: Model:111.11
Gauge: Dial Size:2 in (50 mm)
Gauge: Scale Range:≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar)
Gauge: Pressure Type:Gauge Pressure
Gauge: Measuring Principle:Bourdon Tube
Gauge: Fill Type:Dry
Gauge: Product Unit of Measure:psi / inHg
Gauge: 2nd Scale:bar / psi
Gauge: Process Connection Size:1/4 NPT
Gauge: Process Connection Location:Lower Mount
Gauge: Wetted Material:Copper Alloy (Brass)
Gauge: Accuracy:±3%
Gauge: Case Material:Brass
Gauge: Additional Options:Oil & Grease Free for O2
Specifications
| Gauge: Brand | Wika |
| Gauge: Model | 111.11 |
| Gauge: Dial Size | 2 in (50 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Dry |
| Gauge: Product Unit of Measure | psi / inHg |
| Gauge: 2nd Scale | bar / psi |
| Gauge: Process Connection Size | 1/4 NPT |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Accuracy | ±3% |
| Gauge: Case Material | Brass |
| Gauge: Additional Options | Oil & Grease Free for O2 |
