Wika 213.53 Series Industrial Brass Liquid Filled Pressure Gauge, 0 to 1000 psi
Manufacturer: Wika Instrument Lp
Mfg Product Code: 50416880
Weight: 0.44 lb(s)
On Hand: 0
213.53.2.5" 1000 psi 2nd scale bar 1/4 NPT back mount
Applications
- Intended for adverse service conditions where pulsating or vibration exists (with liquid filling).
- Hydraulics and compressors
- Suitable for gaseous or liquid media that will not obstruct the pressure system.
Product features
- NEW FlexWindow option available on 2-1/2” gauges
- Vibration and shock resistant (with liquid filling)
- Stainless steel case
- Pressure ranges up to 15,000 psi (1,000 bar)
Features
- Bourdon tube pressure gauges ,Stainless Steel case
- case:stainless steel model 213.53.050/063
- Model: 213.53
- Specifications according to data sheet: APM 21X.53 (APM 02.12)
- Measuring System: Copper Alloy
- Case: 304 Stainless Steel
- Case: Non-removable crimp ring
- Nominal size: 2.5"
- Scale range: 0/1000 psi
- 2nd Scale / Special Scale: 2nd scale bar
- Process Connection: 1/4 NPT
- Connector location: back mount
- Mounting Flange/Bracket: front flange, polished SS (Standard)
- Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
- Case filling fluid: Glycerine
- Pointer: Aluminium, Black
- Window: Plastic, clear
- Packing: single packing
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- color for 2.scale (inside): red
- dial background: White
- Manufacturer logo: *WIKA®*
- stop pin on dial: at zero
Wika 213.53 Series Industrial Brass Liquid Filled Pressure Gauge, 0 to 1000 psi
213.53.2.5" 1000 psi 2nd scale bar 1/4 NPT back mount
Measurement Maximum:1000.0
Process Connection Type:NPT
Dial Size:2-1/2 (63 mm)
Fill Type:Glycerin
Max Operating Pressure:1000 psi
Max Operating Temperature:-140 °F
Process Connection Size:1/4"
Process Connection Location:Back (Center)
Case Material:304 SS
Wetted Material:Copper Alloy (Brass)
Measurement Minimum:0
Ingress Protection:IP66
Ring Style:Crimped
2nd/Special Scale:bar
NEMA / UL:NEMA 4X
Specifications
| Measurement Maximum | 1000.0 |
| Process Connection Type | NPT |
| Dial Size | 2-1/2 (63 mm) |
| Fill Type | Glycerin |
| Max Operating Pressure | 1000 psi |
| Max Operating Temperature | -140 °F |
| Process Connection Size | 1/4" |
| Process Connection Location | Back (Center) |
| Case Material | 304 SS |
| Wetted Material | Copper Alloy (Brass) |
| Measurement Minimum | 0 |
| Ingress Protection | IP66 |
| Ring Style | Crimped |
| 2nd/Special Scale | bar |
| NEMA / UL | NEMA 4X |
