Wika 213.53 Series 2.5" Brass Pressure Gauge, 0 to 5000 psi, 1/4" NPT, Liquid Filled w/Heatseal Bag
Manufacturer: Wika Instrument Lp
Mfg Product Code: 50242750
Weight: 0.44 lb(s)
On Hand: 0
213.53 2.5 5000PSI/KPA 1/4 L BAG
Applications
- Intended for adverse service conditions where pulsating or vibration exists (with liquid filling).
- Hydraulics and compressors
- Suitable for gaseous or liquid media that will not obstruct the pressure system.
Product features
- NEW FlexWindow option available on 2-1/2” gauges
- Vibration and shock resistant (with liquid filling)
- Stainless steel case
- Pressure ranges up to 15,000 psi (1,000 bar)
Features
- 213.53 2.5 5000PSI/KPA 1/4 L BAG
- SS Case Pressure Gauge
- Model: 213.53
- Data Sheet according to: APM 21X.53 (APM 02.12)
- Measuring System: Copper Alloy
- Case: 304 Stainless Steel
- Case: Case-Version 53
- Nominal Size: 2.5"
- Range: 5000 psi
- 2nd Scale / Special Scale: 2nd scale kPa
- Process Connection: 1/4"NPT
- Connector Position: Lower Mount
- Additional order details: Heatseal Bag
- Accuracy Class: +/- 2/1/2% (ASME B40.1 Grade A)
- Packing: single packing
- Dial description:
- Pressure Gauge Standard: US-Standard
- color for 1.scale (outside): black
- color for 2.scale (inside): red
- dial background: White
- *WIKA®*
Wika 213.53 Series 2.5" Brass Pressure Gauge, 0 to 5000 psi, 1/4" NPT, Liquid Filled w/Heatseal Bag
213.53 2.5 5000PSI/KPA 1/4 L BAG
Gauge: Brand:Wika
Gauge: Model:213.53
Gauge: Scale Range:≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar)
Gauge: Pressure Type:Gauge Pressure
Gauge: Measuring Principle:Bourdon Tube
Gauge: Fill Type:Liquid Filled / Fillable
Gauge: 2nd Scale:kPa
Gauge: Process Connection Size:1/4 NPT
Gauge: Process Connection Location:Lower Mount
Gauge: Wetted Material:Copper Alloy (Brass)
Gauge: Ingress Protection:IP 65
Gauge: Case Material:Stainless Steel
Gauge: Window Ring:Crimped Ring
Gauge: Additional Options:Heatseal Bag
Specifications
| Gauge: Brand | Wika |
| Gauge: Model | 213.53 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: 2nd Scale | kPa |
| Gauge: Process Connection Size | 1/4 NPT |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Ingress Protection | IP 65 |
| Gauge: Case Material | Stainless Steel |
| Gauge: Window Ring | Crimped Ring |
| Gauge: Additional Options | Heatseal Bag |
