1000 Series Differential Gauge, 0 psid to 50 psid
Manufacturer: Noshok Inc
Mfg Product Code: 45-1012-P50-A3A-1-3
Weight: 1.0 lb(s)
4.5" Differential, 0 to 50 psid, 2 x 1/4" NPT Back Gauge, Aluminum Sensor Housing, NBR O-Ring, Aluminum Case, Shatter-Resistant Acrylic Lens, Single Switch, 1/4" Female NPT Flying Leads, NEMA 4X
- Simple, rugged, compact differential pressure gauge
- Ranges from 0 psid to 5 psid through 0 psid to 110 psid
- Engineered plastic gauge case
- Clear anodized Aluminum and 316 Stainless Steel wetted parts
Applications:
- Back flow testing
- Heat exchangers
- Filter monitoring
- Flow indication
- Level indication
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
1000 Series Differential Gauge, 0 psid to 50 psid
4.5" Differential, 0 to 50 psid, 2 x 1/4" NPT Back Gauge, Aluminum Sensor Housing, NBR O-Ring, Aluminum Case, Shatter-Resistant Acrylic Lens, Single Switch, 1/4" Female NPT Flying Leads, NEMA 4X
Valve: Diaphragm Material:NBR
Brand_Name:Noshok
Measurement Maximum:50.0
Process Connection Type:NPT-Female
Dial Size:4-1/2 in (115 mm)
Pressure Range:0 psid to 50 psid
Min Operating Pressure:0 psid
Max Operating Pressure:50 psid
Min Operating Temperature:-40 °F
Product Unit of Measure:psid
Max Operating Temperature:200 °F
Process Connection Size:1/4"
Process Connection Location:Back
Lens Material:Shatter-resistant Acrylic
Accuracy:±3/2/3% of full scale on rising pressure
Case Material:Aluminum
Wetted Material:Aluminum
Measurement Minimum:0
O-Ring:NBR
O-Ring Material:NBR
Specifications
| Valve Features | |
|---|---|
| Valve: Diaphragm Material | NBR |
| Uncategorized | |
|---|---|
| Brand_Name | Noshok |
| Measurement Maximum | 50.0 |
| Process Connection Type | NPT-Female |
| Dial Size | 4-1/2 in (115 mm) |
| Pressure Range | 0 psid to 50 psid |
| Min Operating Pressure | 0 psid |
| Max Operating Pressure | 50 psid |
| Min Operating Temperature | -40 °F |
| Product Unit of Measure | psid |
| Max Operating Temperature | 200 °F |
| Process Connection Size | 1/4" |
| Process Connection Location | Back |
| Lens Material | Shatter-resistant Acrylic |
| Accuracy | ±3/2/3% of full scale on rising pressure |
| Case Material | Aluminum |
| Wetted Material | Aluminum |
| Measurement Minimum | 0 |
| O-Ring | NBR |
| O-Ring Material | NBR |
