Wika 700.04 Series 4.5" Differential Pressure Gauge, 0 to 100 psid, 2x 1/4 NPTF, Back Entry
Manufacturer: Wika Instrument Lp
Mfg Product Code: 4372162
Weight: 1.68 lb(s)
On Hand: 0
700.04 4.5" 100 psid 2 x 1/4 NPT Female
Applications
- For use in measurement applications requiring high differential / static process pressures.
- Suitable for measuring pressure drops across filters, strainers, separators, etc.
Product Features
- Magnetic piston sensing element
- Rugged thermoplastic case
- Field liquid fillable
- 6000 psig (400 barg) maximum working pressure
- Differential pressure ranges to 100 PSID (7 bard)
Features
- Type 70X.04 DP Gauge with Magnetic-Piston Sensing Element
- Model: 700.04
- Material of Wetted Parts: Ceramic magnet and 316 SS
- Overpressure Safety/Working Pressure Maximum: PN 400 bar
- Accuracy Class: +/- 2% of span ascending
- Nominal Size: 4.5"
- Measuring System: Stainless Steel
- Scale Range: 100 psid
- Window: acrylic (PMMA)
- Process Connection: 2 x 1/4 NPT Female
- Connector location: 2 x back entry
- serial number on dial: Serial number *...*
- color for 1.scale (outside): black
- Mark on Dial: Δp
- norm-mark on dial: *Assembled in USA*
- Manufacturer logo: *WIKA®*
- stop pin on dial: at zero and full scale
Wika 700.04 Series 4.5" Differential Pressure Gauge, 0 to 100 psid, 2x 1/4 NPTF, Back Entry
700.04 4.5" 100 psid 2 x 1/4 NPT Female
Gauge: Brand:Wika
Gauge: Model:700.04
Gauge: Dial Size:4-1/2 in (110 & 115 mm)
Gauge: Scale Range:≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar)
Gauge: Pressure Type:Gauge Pressure
Gauge: Measuring Principle:Capsule Element
Gauge: Fill Type:Dry
Gauge: Product Unit of Measure:psid
Gauge: Process Connection Size:1/4 NPT Female
Gauge: Process Connection Location:2 x Back Entry
Gauge: Process Connection Type:2-Way (2 x)
Gauge: Wetted Material:Stainless Steel
Gauge: Accuracy:±2%
Gauge: Case Material:Thermoplastic
Specifications
| Gauge: Brand | Wika |
| Gauge: Model | 700.04 |
| Gauge: Dial Size | 4-1/2 in (110 & 115 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Capsule Element |
| Gauge: Fill Type | Dry |
| Gauge: Product Unit of Measure | psid |
| Gauge: Process Connection Size | 1/4 NPT Female |
| Gauge: Process Connection Location | 2 x Back Entry |
| Gauge: Process Connection Type | 2-Way (2 x) |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Accuracy | ±2% |
| Gauge: Case Material | Thermoplastic |
