Wika 232.53 Series 2" SS Dry Pressure Gauge, 0 to 200 psi, 1/4 NPT, LM
Manufacturer: Wika Instrument Lp
Mfg Product Code: 4282923
Weight: 0.35 lb(s)
This high-quality Bourdon tube pressure gauge has been designed especially for the process industry.
The use of high-quality stainless steel materials and the robust design are geared to applications in the chemical and process engineering industries. Thus the instrument is suitable for liquid and gaseous media, also in aggressive environments.
Applications
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive environments
- Chemical and petrochemical industries, oil and gas industry, power engineering and also water and wastewater technology
- Machine building and general plant construction
Features
- Pressure Gauge, size 2.0" Stainless Steel, crimped bezel
- Measuring System: Stainless Steel
- Case: Non-removable crimp ring
- Scale range: 0/200 psi
- Process Connection: 1/4 NPT
- Connector location: lower mount
- Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
- Material pressure element: Measuring System 316 SS
- Window: Polycarbonate
- Dial description:
- Pressure Gauge Standard: US-Standard
- Color for 1.scale (outside): black
- Dial background: White
- WIKA®
- Serial number on dial: Serial number ...
- Stop pin on dial: at zero
Wika 232.53 Series 2" SS Dry Pressure Gauge, 0 to 200 psi, 1/4 NPT, LM
Gauge: Brand:Wika
Gauge: Model:232.53
Gauge: Dial Size:2 in (50 mm)
Gauge: Scale Range:≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar)
Gauge: Pressure Type:Gauge Pressure
Gauge: Measuring Principle:Bourdon Tube
Gauge: Fill Type:Dry
Gauge: Product Unit of Measure:psi
Gauge: Process Connection Size:1/4 NPT
Gauge: Process Connection Location:Lower Mount
Gauge: Wetted Material:Stainless Steel
Gauge: Accuracy:±2%
Gauge: Case Material:Stainless Steel
Specifications
| Gauge: Brand | Wika |
| Gauge: Model | 232.53 |
| Gauge: Dial Size | 2 in (50 mm) |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Fill Type | Dry |
| Gauge: Product Unit of Measure | psi |
| Gauge: Process Connection Size | 1/4 NPT |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Accuracy | ±2% |
| Gauge: Case Material | Stainless Steel |
