Barksdale 425 Gen. Industrial Transducer, 4 to 20 mA Analog Output, M12 Hirschman Conn., 0 to 3,000 psig (0 to 207 barg), 1/4-8 NPT

Manufacturer: Barksdale Inc Dba Dynalco Controls Corp

Mfg Product Code: 425T4-13

Weight: 1.0 lb(s)

Product Series 420
Family Series Barksdale Control Products Transducers, 420 Series
Pressure Range (Gauge) 0-3,000 psi
Max Pressure (Gauge) 3,000 psi
Input 12-32 VDC
Output 4-20 mA
Electrical Connection M12 Hirschman Connector
Pressure Connection 1/4-18 NPT Male
Temperature Range -40-185 °F

Barksdale's Series 423, 426 Transducers and 425 Transmitters offer a robust and accurate solution for a wide range of industrial pressure sensing applications.

Key Features:

• High Accuracy:
  • Achieves 0.25% accuracy with a stable, diffused silicon sensor.
• Rugged Construction:
  • Constructed with 17-4PH and 300 Series Stainless Steel for durability.
  • NEMA 4 enclosures constructed of 304 Stainless Steel for added protection.
• Versatile Outputs:
  • Available in 5V, 10V, or 4-20 mA outputs to suit various system requirements.
• Enhanced Performance:
  • Built-in high pressure snubbers (standard on units at 2,000 psi and above) for improved reliability.
  • Superior surge voltage protection (optional up to 6kV) for enhanced durability.
• Wide Pressure Range:
  • Handles pressures from 0-10,000 psi.

Applications:

• Industrial hydraulic equipment
• Cranes
• Compressors
• Gas metering
• Vacuum machinery
• Packaging
