400 Series Stainless Steel Dry Pressure Gauge, 0 psi to 15,000 psi
Manufacturer: Noshok Inc
Mfg Product Code: 40-400-15000-psi/kg/cm2-1/4
Weight: 0.8 lb(s)
4" 304 SS Case, 316 SS Internals, 15,000 psi/kg/cm², 1/4" (NPT) Male Bottom
- Corrosion-resistant fillable dry or liquid-filled gauge
- Vacuum and compound ranges through 0 psi to 20,000 psi
- 316 Stainless Steel wetted parts
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
Applications:
- Chemical processing
- Oil field & offshore
- Paper mills
- Agriculture plants
- Marine
- Water & wastewater
WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
400 Series Stainless Steel Dry Pressure Gauge, 0 psi to 15,000 psi
4" 304 SS Case, 316 SS Internals, 15,000 psi/kg/cm², 1/4" (NPT) Male Bottom
Measurement Maximum:15000.0
Process Connection Type:NPT-Male
Dial Size:4 in (100 mm)
Max Operating Pressure:15000 psi
Max Operating Temperature:392 °F
Process Connection Location:Bottom
Lens Material:Instrument Glass
Accuracy:±1% full scale
Case Material:304 SS
Measurement Minimum:0
Specifications
| Measurement Maximum | 15000.0 |
| Process Connection Type | NPT-Male |
| Dial Size | 4 in (100 mm) |
| Max Operating Pressure | 15000 psi |
| Max Operating Temperature | 392 °F |
| Process Connection Location | Bottom |
| Lens Material | Instrument Glass |
| Accuracy | ±1% full scale |
| Case Material | 304 SS |
| Measurement Minimum | 0 |
