300 Series High Pressure Switch, Adjustable Hysteresis, 145 to 1,750 psig, 1/4" NPT-Male, SPDT, DIN EN 175301-803 Form A w/ 36" Cable
Manufacturer: Noshok Inc
Mfg Product Code: 300H-3-2-145/1750-1
Weight: 0.01 lb(s)
- Switch adjustment ranges from vacuum through 4,600 psig
- Standard Zinc-nickel with NBR diaphragm wetted parts
- SPST or SPDT snap-action switch with solid Silver contacts
- CE compliant to suppress Radio Frequency Interference (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD)
- RoHS compliant
Applications:
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
300 Series High Pressure Switch, Adjustable Hysteresis, 145 to 1,750 psig, 1/4" NPT-Male, SPDT, DIN EN 175301-803 Form A w/ 36" Cable
Measurement Maximum:1750.0
Process Connection Type:NPT-Male
Max Operating Pressure:1750 psid
Max Operating Temperature:176 °F
Process Connection Size:1/4"
Case Material:Zinc-Nickel Plated Steel
Measurement Minimum:145
Ingress Protection:IP65
Switch Function:SPDT
Electrical Connector Type:DIN EN 175301-803 Form A
Specifications
| Measurement Maximum | 1750.0 |
| Process Connection Type | NPT-Male |
| Max Operating Pressure | 1750 psid |
| Max Operating Temperature | 176 °F |
| Process Connection Size | 1/4" |
| Case Material | Zinc-Nickel Plated Steel |
| Measurement Minimum | 145 |
| Ingress Protection | IP65 |
| Switch Function | SPDT |
| Electrical Connector Type | DIN EN 175301-803 Form A |
