400 Series Stainless Steel Dry Pressure Gauge, 0 psi to 30 psi, Rubber Case Protector
Manufacturer: Noshok Inc
Mfg Product Code: 25-410-30-psi/bar-RCP
Weight: 1.0 lb(s)
2.5" 304 SS Case, 316 SS Internals, 30 psi/bar, 1/4" (NPT) Male Back
- Corrosion-resistant fillable dry or liquid-filled gauge
- Vacuum and compound ranges through 0 psi to 20,000 psi
- 316 Stainless Steel wetted parts
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
- For gauges with MIP, GY40 fill is standard for liquid filled gauges
Applications:
- Chemical processing
- Oil field & offshore
- Paper mills
- Agriculture plants
- Marine
- Water & wastewater
WARNING: This product can expose you to chemicals including Nickel, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
400 Series Stainless Steel Dry Pressure Gauge, 0 psi to 30 psi, Rubber Case Protector
2.5" 304 SS Case, 316 SS Internals, 30 psi/bar, 1/4" (NPT) Male Back
Measurement Maximum:30.0
Process Connection Type:NPT-Male
Dial Size:2-1/2 (63 mm)
Pressure Range:0 psi to 30 psi
Min Operating Pressure:0 psi
Max Operating Pressure:30 psi
Min Operating Temperature:-40 °F
Product Unit of Measure:psi/bar dual scale
Max Operating Temperature:392 °F
Process Connection Size:1/4"
Process Connection Location:Back
Lens Material:Trogamide
Accuracy:±1.6% full scale
Case Material:304 SS
Wetted Material:316 SS
Measurement Minimum:0
Specifications
| Measurement Maximum | 30.0 |
| Process Connection Type | NPT-Male |
| Dial Size | 2-1/2 (63 mm) |
| Pressure Range | 0 psi to 30 psi |
| Min Operating Pressure | 0 psi |
| Max Operating Pressure | 30 psi |
| Min Operating Temperature | -40 °F |
| Product Unit of Measure | psi/bar dual scale |
| Max Operating Temperature | 392 °F |
| Process Connection Size | 1/4" |
| Process Connection Location | Back |
| Lens Material | Trogamide |
| Accuracy | ±1.6% full scale |
| Case Material | 304 SS |
| Wetted Material | 316 SS |
| Measurement Minimum | 0 |
