300 Series Brass Case Liquid Filled Pressure Gauge, 0 psi to 600 psi, Maximum Indicating Pointer
Manufacturer: Noshok Inc
Mfg Product Code: 25-300-600-PSI-SST-MIP
Weight: 0.5 lb(s)
2.5" Brass Case, Copper Alloy Internals, 1,000 psi/bar, 7/16-20 Male Bottom, Glycerin Fill & Maximum Indicating Pointer
- High quality, heavy-duty liquid filled gauge
- Vacuum and compound ranges through 0 psi to 15,000 psi
- Die cast Brass case with natural Brass finish
- Copper alloy or 316 Stainless Steel and Brass wetted parts
- Cleaning for Oxygen Service (O2) is available only for dry or HL (Halocarbon) filled gauges
- For gauges with MIP, GY40 fill is standard for liquid filled gauges
Applications:
- Automotive
- Construction
- Hydraulics & pneumatics
- Mining
- Stamping & forming presses
- Transportation
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
300 Series Brass Case Liquid Filled Pressure Gauge, 0 psi to 600 psi, Maximum Indicating Pointer
2.5" Brass Case, Copper Alloy Internals, 1,000 psi/bar, 7/16-20 Male Bottom, Glycerin Fill & Maximum Indicating Pointer
Measurement Maximum:1000.0
Process Connection Type:SAE-Adjustable
Dial Size:2-1/2 (63 mm)
Pressure Range:0 psi to 300 psi
Min Operating Pressure:0 psi
Max Operating Pressure:300 psi
Min Operating Temperature:-4 °F
Product Unit of Measure:psi/bar dual scale
Max Operating Temperature:140 °F
Process Connection Size:7/16"-20
Process Connection Location:Bottom
Accuracy:±1.6% full scale
Case Material:Brass
Wetted Material:Copper Alloy
Measurement Minimum:0
Specifications
| Measurement Maximum | 1000.0 |
| Process Connection Type | SAE-Adjustable |
| Dial Size | 2-1/2 (63 mm) |
| Pressure Range | 0 psi to 300 psi |
| Min Operating Pressure | 0 psi |
| Max Operating Pressure | 300 psi |
| Min Operating Temperature | -4 °F |
| Product Unit of Measure | psi/bar dual scale |
| Max Operating Temperature | 140 °F |
| Process Connection Size | 7/16"-20 |
| Process Connection Location | Bottom |
| Accuracy | ±1.6% full scale |
| Case Material | Brass |
| Wetted Material | Copper Alloy |
| Measurement Minimum | 0 |
