2160 Series Aerosol Filter 100 SCFM, 98% Efficiency
Manufacturer: Noshok Inc
Mfg Product Code: 2160-3-5
Weight: 16.0 lb(s)
On Hand: 0
2160 Series 100 scfm Aerosol Filters
- Designed for final clean-up of compressed air
- Utilizes media with a natural affinity for fine droplets (aerosols) of oils and water
- Adsorptive element removes even the smallest sub-micron particles and contaminants to deliver clean, dry, and oil-free air
2160 Series Aerosol Filter 100 SCFM, 98% Efficiency
2160 Series 100 scfm Aerosol Filters
Brand_Name:Noshok
Process Connection Type:NPT
Process Connection Size:1"
Housing Material_:Aluminum
Flow @ 100 psig:100 SCFM
Flow @ 7 kg/cm2:2832 LPM
Flow @ 7 bar:170 CMH
Efficiency:98%
Max Inlet Pressure:150 psi
Filter Type:Single Absorptive Element
Specifications
| Brand_Name | Noshok |
| Process Connection Type | NPT |
| Process Connection Size | 1" |
| Housing Material_ | Aluminum |
| Flow @ 100 psig | 100 SCFM |
| Flow @ 7 kg/cm2 | 2832 LPM |
| Flow @ 7 bar | 170 CMH |
| Efficiency | 98% |
| Max Inlet Pressure | 150 psi |
| Filter Type | Single Absorptive Element |
