Turck Inductive Sensor (BI15U-CP40-VN4X2/S10)

Manufacturer: Turck Incorporated

Mfg Product Code: 1540511

Weight: 0.45 lb(s)

Shielding Shielded
Power Type DC
Range 15 mm
Number of Wires 4
Body Composition Non-Metallic
Operating Voltage Range 10-65 VDC
Nominal Voltage 12 VDC, 24 VDC, 48 VDC
Sensing Type End
Status Indicator Yes
Short Circuit Protection Yes
Max Leakage Current 0.1 mA
RoHS Yes

Inductive Sensor Features

• Rated switching distance 15 mm
• Flush
• Rectangular
• height 40 mm
• Variable orientation of active face in 9 directions
• Plastic
• PBT‐GF30‐V0
• High luminance corner LEDs
• Optimum view on supply voltage and switching state from any position
• Factor 1 for all metals
• Protection class IP68
• Resistant to magnetic fields
• Extended temperature range
• High switching frequency
• DC 4-wire
• 10…65 VDC
• Changeover contact
• NPN output
• Terminal chamber
