Flomec FM Approved Remote Kit Assembly for Turbine Flow Meters with Q9 Display
Manufacturer: Great Plains Industries (GPI/Flomec)
Mfg Product Code: 113275-10
Weight: 1.0 lb(s)
On Hand: 0
The Factory Mutual (FM) Approved Remote Kit Assembly modifies FLOMEC® electronic digital meters for applications in specialized situations including remote indication and high or low fluid temperature metering applications. This kit provides the versatility of panel mounting of the LCD readout up to 100 feet (30 meters) from the turbine. This kit consists of a sensor module, a dust cover assembly, and 10 feet (3 meters) of cable. Requires a complete meter with a Q9 display.
| SPECIFICATIONS | |
|---|---|
| Magnetic Pickup: | 1.3k Ohm, 90mH |
| Signal Type: | Sine Wave |
| Voltage: | Peak to Peak, 10 mV to 500 mV |
| Frequency: | 11 to 608 Hz |
| Cable: | 10 ft. (3 m), 2-conductor shielded, Belden #9501 |
Features & Benefits
- Maintains FM Approval
- Accommodates fluid temperatures from -40°F to +250°F (-40°C to +121°C) depending on meter
- This kit can upgrade an existing FLOMEC meter (with Q9 display) or can be purchased with a new meter
- Battery-powered display, no additional power required
- Use with the A1, G2, TM, and 03 Series meters
