Turck Temperature Detection, With Current or Voltage Output and PNP/NPN Transistor Switching Output (TS720-LI2UPN8-H1141)

Manufacturer: Turck Incorporated

Mfg Product Code: 100003640

Weight: 0.65 lb(s)

measurement range -200°C...+1800°C - 4-pin M12 Eurofast QD male connector + M12 threaded male connection port - 1 x analog output (4-20mA; can be used as a NPN/PNP digital output) - 1.4404 (316L) stainless steel housing - supply voltage 18-30Vdc (24Vdc nom.) - IP69K - Rated for +12.5psi...15.4psi / +0.8...+1bar fluid circuits - Rated for -40°C...+80°C ambient - with LED display (4-digit)

Temperature Detection Features

• With Current or Voltage Output and PNP/NPN Transistor Switching Output
• Processor unit for connecting sensors from the TP product series
• Automatic probe detection
• 4-digit
• two-colored
• 12-segment display
• rotatable by 180°
• Upper part of housing can be rotated up to 340°
• 17…33 VDC
• NO/NC contact
• PNP/NPN output
• analog output (current/voltage)
• IO-Link
• Various IO-Link mapping profiles can be selected
