Turck Level Sensor, With Analog Output and 2 × Switching Outputs (LS-534-0000-LIU22PN8X-H1151)
Manufacturer: Turck Incorporated
Mfg Product Code: 100001845
Weight: 1.23 lb(s)
On Hand: 0
Level Sensor Features
- With Analog Output and 2 × Switching Outputs
- Multiple output signals: one system for both level detection and continuous level monitoring
- Low maintenance and quick commissioning without calibration
- High flexibility due to cutable probe
- Compact
- rotatable display housing ensures easy installation
- Small inactive areas
- ideal for small containers
- Process temperature to 212 °F
- Process pressure up to 145 psi
- Coaxial tubes available for non-metallic tanks
- IO-Link 1.1
- 12…30 VDC
- 1 × analog output 4… 20 mA/0… 10 V (automatic switchover depending on load)
- 2 × PNP/IO-Link or PNP/NPN transistor outputs
- each switchable
Turck Level Sensor, With Analog Output and 2 × Switching Outputs (LS-534-0000-LIU22PN8X-H1151)
Measurement Maximum:0
Process Connection Type:NPT
Measurement Minimum:0
Specifications
| Measurement Maximum | 0 |
| Process Connection Type | NPT |
| Measurement Minimum | 0 |
