Turck Pressure Sensor, Relative Pressure: -1…10  Bar (PS510-10V-03-LI2UPN8-H1141)

Manufacturer: Turck Incorporated

Mfg Product Code: 100001528

Weight: 0.61 lb(s)

Measuring range 0...+10bar - 4-pin M12 Eurofast QD male connector + 1/4" NPT threaded male process port - 1 x analog output (4-20mA / 0-10Vdc; can be used as a NPN/PNP digital output) - 1.4404 (316L) stainless steel housing - supply voltage 18-30Vdc (24Vdc nom.) - IP66 - Rated for -40°C...+80°C ambient - with LED display (4-digit) + LED indicators - equivalent to PS51010V03LI2UPN8H1141

Pressure Sensor Features

• Relative Pressure: -1…10  Bar
• 4-digit
• 2-colored
• 12-segment display
• rotatable by 180°
• Housing is rotatable after plugging the process connection
• Metal measuring cell
• 18…33 VDC
• NO/NC contact
• PNP/NPN output
• analog output (current/voltage)
• IO-Link
• Process connection 1/4" NPT male thread
• Connector device
• M12 × 1
